Specification: Item Type: Automatic Tool Setting Gauge Output Mode: B: NC (normally closed) Stroke: 5mm Repeatability: 0.001mm Electric Shock Life: 3 million times Structure: IP67 Force: 1.5N Material of the Area: Hard-bonding Housing Material: Ground 4S Tube: 1 meters minimum bending radius R25 Cable: 2 meters oil 4-core Electrical Aspects: 1. rating DC24V ¡À 10% 20mA (maximal) 2. When the body of the machine is grounded, use the tool setter to install it on the side of the ground wire. 3. For the tool setting instrument with LED, pay attention to the connection (+) (-) when connecting. Recommended value is 10mA, load. 4. For the output structure when the interface unit is attached, please read the user manual Package List: 1 x Automatic Tool Setting Gauge Note: 1. Please control the tool setting speed at 50 ~ 200mm / min 2. Operating ambient temperature range: 0 ~ 80 3. Please control the voltage at DC24V and the current below 20mA

• Alarm can be sent when overtravel, The shell is made of ground 4S material, and not easy to damage.
• After-sales: If you have any questions after purchase, please us in time, we will answer your questions seriously and provide high-quality after-sales service.
