Interval time - 1 - 256 min. Adjustable, drain time - 4 sec, supply voltage - 230 vac, (160 - 260), 50 Hz, (other on request), operating temp. - 70 degrees(maximum), housing material - high impact resistant ABS, connection - din 43650 a with power indication, indications - LED (red), power - on, LED (yellow) - on after every 15 sec. Indicate healthyness of timer (available in most drain) LED (green) - on during drain cycle, valve, type - 2/2 way direct acting, in/out ports - 1/2" bsp (f), working pressure - 16kg. /Cm2, valve body - bar stack aluminium with anodizing, orific - 2. 5 mm.
