It is environmental protection design, food grade material POM, small, practical, and can be arbitrary Angle regulation. It is for the G1/4 the tooth type structures, unions, more convenient, can match fast by type nut and pipe plug. 1. output voltage (rated DC5V) : high level 4.5 V above, low level 0.5 V the following; Pulse output occupies emptiescompared to 50-10% 2. Appearance: Clean and beautiful, smooth without burr, without off color 3. Mode of connection-Red: the positive, black: negative, yellow: pulse signal 4. Water flow sensor (water flow sensor) and flow switch (flow switch) outlet terminals installation dimensions for the connection mode and the length of the connecting according to request, the water flow sensor existing pipe diameter have G1/4, G1/2 and straight intubation (equivalent to the G1/4) three, press Angle points can be divided into 90 degrees and 180 degrees two kinds, has the plastic shell and cast-bronze piece two kind of material, mainly for the water heater, wall-hang boiler, water machine. It has Hall element for Japan imports, sensitive and reliable having Flow range: 0.3- 3 L/min(In stock);0.5-6L/min(Customize).working voltage: DC5-24 V, Rated voltage DC5V.It is designed for small flow and medicine machinery make water flow sensor, but also be used for electrical and mechanical equipment.The Flow accuracy near 2%,and the Pulse character is 4000Hz/L.

• Output Waveform:Square Wave,output pulse signal.
• Work for Android and PI system.
