Kindly Note If the gate operator system is only solar powered, and the beam sensor is powered by the gate opener system during both working and standby modes, please add 30W solar panels or more and upgrade the battery capacity (NOT incl.) to at least 17 Ah or higher to meet the power consumption. Please refer to the corresponding TOPENS gate opener user manual for the correct wire connection. Connect the emitter to the gate operator system or receiver with a 2C x 22 AWG cable. Connect the receiver to the gate operator system with a 4C x 22 AWG cable. Cables are required but NOT included. It is suggested to put the cables in the PVC conduit to protect the wiring, and bury the PVC conduit underground. Generally, the distance between the sensor and the control board should be within 65 feet (20m). Sensing range may be affected in extreme weather conditions, such as blizzard, rainstorm, sandstorm etc. It is highly recommended to install the emitter 10 feet (3m) to 46 feet (14m) away from the receiver. One TC102 photocell sensor can only work for one gate operator, while one gate operator can connect two TC102 security sensors at most. Specifications Detection Method: Interrupt Detection Beam Type: Infrared Light Wave Length: 940nm Frequency: 1.92 KHz Angle: <10° Max. Sensing Range: 65ft. (20m) Response Time: 10ms (Max) Operating Voltage: 12-24VDC / VAC Rated Current: RX 15mA - TX 30mA Output: Relay SPDT Output Capacity: 1A max 30V Protection Degree: IP44 Working Temperature: 0°F to 120°F (-20℃~ +50℃) Dimension of the Sensor: 3 x 1.9 x 1.2” (75 x 48 x 30 mm) What's in the Box 1 x Photocell Beam Sensor (One Emitter and One Receiver) 1 x Mounting Accessories 1 x TOPENS User Manual

• Easy DIY Installation - Connect both the receiver and the emitter to the gate opener system. It is suggested to mount the photocell sensor at least 8" (20cm) above the ground. Power on to determine the emitter position. The photocell status LED turns off indicating that the beam is aligned. Fix the emitter position when the status LED goes off. Ensure that there is no obstruction between the receiver and the emitter during alignment.
• Customer Service and Technical Support - All the TOPENS products come with a 12-month war-ranty against defects, a 30-day worry-free exchange & return and lifetime tech support. Visit TOPENS website for the user manual, installation video, and personalized service. TOPENS is ready to offer professional solutions for any questions or assistance. Enjoy an easier and smarter life by ordering other TOPENS accessories.
